Challenge 305 XG, 1998

Challenge 305 XG, 1998

$13,500 (USD)

orCall 704-936-9049

Description

Challenge 305 XG,1998


Serial #98X418


Air Bed

Specifications

ManufacturerChallenge
Model305 XG
Year1998
ConditionUsed
Serial Number98X418
Stock Number2509
Maximum Cutting Width30 1/2"
Minimum Cut without false clamp plate3/4" with false clamp plate: 2"
Maximum Cut Depth30-1/2"
Clamp Opening3-3/4"
Clamping MethodHydraulic and Manual
Maximum Clamping Force5000 lbs / 2200 daN
Backgauge ControlPower and Manual
DimensionsTable Height 36 1/2" Table Space: in front of knife 25" behind knife 30-1/2"
Overall Height58 1/2"
Overall Width (with side tables)78 1/2"
Overall Width (without side tables)48-1/2'
Overall Length70"
Mounting Dimension41-1/2" with table/treadle removed: 42" with table/treadle/power unit removed : 29"
Door Pass-throughassembled 49"
Weight2,550 lbs.
Electrical208/230 Volts AC, 3 Phase/60 Hz, 25Amps (Service size 20 Amps)
Unique id20210413DNC98X418
