Horizon HT-30 Trimmer, 2011 Video
Horizon HT-30 Trimmer, 2011 Video
$42,000 (USD)
Description
Horizon HT-30 Trimmer, 2011
Serial #335012
Specifications
| Manufacturer | Horizon |
| Model | HT-30 |
| Year | 2011 |
| Condition | Used |
| Serial Number | 335012 |
| Stock Number | 3049 |
| Untrimmed Book Size | Max. 12.59" x 9.25" Min. 7.88" x 5.28" |
| Trimmed Book Size | Max. 12.00" x 9.05" |
| Trimmings Width | Max. 3.93" Min. 0.08" |
| Trim Thickness | Max. 2.0" |
| Book Pile Height | Max.11.8" |
| Clamp and Pressure | Hydraulically Operated |
| Automatic Settings | 4 kN / 5.5 kN / 8 kN, 3 Steps Selectable |
| Manual Settings | 1.5 kN / 3 kN / 5 kN / 6.5 kN / 8 kN, 5 Steps Selectable |
| Production Speed | Max. 400 books/hr. (Book Thickness 25 mm, 2 piled books); Max. 500 books/hr. (Book Thickness 10 mm, 5 piled books) |
| Temperature & Humidity | Temperature : +10 C to +30 C, Humidity : 30 % to 80 %RH |
| Heat Output | 3,950 kJ |
| Motors | 2.2 kW x 1 / 0.41 kW x 1 / 0.40 kW x 1 / 0.325 kW x 1 / 40 W x 2 / 15 W x 1 |
| Dimensions | 92.6" W x 45.7" D x 54.0" H Weight: 2,073 lbs. |
| Electrical | 220V 3 Phase 60 Hz 3.5Amps |
| Unique id | 20240503DNC335012 |
