Horizon RD-4055 DM, 2019
Horizon RD-4055 DM, 2019
$135,000 (USD)
Description
Horizon RD-4055 DM, 2019
Serial #041301
Specifications
| Manufacturer | Horizon |
| Model | RD-4055DM |
| Year | 2019 |
| Condition | Used |
| Serial Number | 041301 |
| Stock Number | 3341 |
| Max. Sheet Size | 15.74" x 21.65" |
| Min. Sheet Size | 7.875" x 10.83" |
| Feeder Stacker Height | 19.68" |
| Material Thickness | 127.9 to 400gsm Die Cutting: Max. 0.5 mm or 0.019" Creasing: Max. 0.3 mm or 0.011" |
| Production Speed | 6,000 cycles per hour |
| Double sheet detection | Ultrasonic and mechanical |
| Processed Material | Normal paper, Coated paper, Cardboard The sheets below cannot be processed: Sheet whose back side is laminated (cover with polypropylene) Plastic film |
| Available Cutting Area | 14.8" W x 20.8" L |
| Die Size - Upper Die | Max. 15.74" W x 22.04" L Min. 6.30" W x 3.94" L |
| Upper Cutting Blade Height | 0.0315" |
| Gripping width for Repeat Die Cutting | 6.69"(includes the cut product at least) |
| Dimensions | With separator: 141.2" W x 32.3" D x 47.1" H Weight: 1,962.45 lb |
| Air Requirements | Rated Output of Prime Mover(Reference): 0.75 kW Maximum Operating Pressure: 0.8 MPa Minimum Required Pressure: 0.6 MPa or more Minimum Discharge: 85 Liters per minute Type: Oil-free Type |
| Electrical | Single Phase 200 to 240 V, 50 or 60 Hz |
| Unique id | 20260303DNC041301 |
