Duplo DBMi Saddle System with DSF-CFL Sheet Feeder & Cover Feeder, 2015
Duplo DBMi Saddle System with DSF-CFL Sheet Feeder & Cover Feeder, 2015
$65,000 (USD)
Description
Duplo DBMi Saddle System with DSF-CFL Sheet Feeder & Cover Feeder, 2015
Serial #150901023
Specifications
| Model | DBMi |
| Year | 2015 |
| Condition | Used |
| Serial Number | 150901023 |
| Stock Number | 3378 |
| Paper type | Fine quality paper 64 to 157gsm |
| Art/Coated paper | 84.9 to 157gsm |
| Cover sheet | 300 gsm |
| Paper size | Saddle stitching/Length 210 to 610 mm Width 120 to 356 mm |
| Type of stitching | Saddle Stitch |
| Maximum booklet thickness | 6.0mm (1 Cover sheet + 29 inner sheets) |
| Maximum processing speed | A4 size, within 10 sheets 5,050sets/h A3 size, within 10 sheets 4,000sets/h |
| Thickness of Scoring/Folding | 1.0mm (DBMS-S5 stack sub-sets on the buffer section) |
| Trimming Width | 1 to 25mm |
| Number of stitch | 0 to 2 ( 3 or 4 stitch is available by optional equipment) |
| Detecting function 【DBMS-F5】 | Paper jam, Cover open/close, Motor overload detection |
| Detecting Function【DBMS-S5】 | Paper jam, No stitch detection, Stitcher dislocation detection, Cover open/close, Motor overload detection |
| Detecting Function 【DBMS-T5】 | Paper jam, Cover open/close, Knife stop position error, Motor overload detection |
| Rating and power consumption 【DBMS-S5】 | 200 to 240V, 50/60Hz, 3.0A, 510W |
| Rating and power consumption【DBMS-T5】 | 200 to 240V, 50/60Hz, 2.5A, 355W |
| Unique id | 20261504DNC150901023 |
